IMC PID Tuning for Process Control Loops Using FOPDT and SOPDT Transfer Function Models

on

The purpose of this article is to provide a practical, model-based workflow for closed-loop PID tuning using IMC (Internal Model Control) correlations built from simple transfer function models, so you can move from plant test data to robust PID settings with predictable performance.

1. Why IMC PID tuning is widely used in industry.

IMC PID tuning is a model-based method that converts a simple process model into PID parameters using one main “speed” knob, usually called the IMC filter or closed-loop time constant, commonly denoted as λ or τc.

This approach is popular for process control loops because it ties tuning to measured dynamics such as process gain, time constant, and dead time, and it allows systematic trade-offs between fast response and robustness.

Note : IMC-based tuning is only as good as the identified model and the validity of the test data, so the identification step and basic data hygiene matter as much as the final equations.

2. Closed-loop tuning starts with an open-loop model.

2.1 Transfer function models used for IMC PID tuning.

Most practical IMC PID correlations assume you can represent the loop’s process dynamics with one of these linear time-invariant models around the operating point.

Model name. Transfer function form. Typical use case. Parameters to identify.
FOPDT (First-Order Plus Dead Time). Gp(s) = Kp · e−θp s / (τp s + 1). Single dominant lag with noticeable transport delay. Kp, τp, θp.
SOPDT (Second-Order Plus Dead Time). Gp(s) = k · e−θ s / ((τ1 s + 1)(τ2 s + 1)). Two dominant lags, sluggish temperature and composition loops, and many large-volume systems. k, τ1, τ2, θ.
Integrating plus dead time. Gp(s) = k0 · e−θ s / s. Level loops and near-integrating behavior due to large time constants. k0, θ.

2.2 How to collect usable data from a plant test.

A reliable IMC PID tuning workflow typically uses a step test on the manipulated variable while the controller is in manual, or uses a closed-loop identification test that keeps the loop stable while exciting it gently.

For a manual step test, a common procedure is to wait for steady operation, apply a small step in controller output, and record the time trend of the process variable until it approaches a new steady value.

Note : Step tests should be sized and timed to stay within safety, quality, and constraint limits, and the test must be done at the same operating point where the tuning will be used.

2.3 Quick identification from a step response for an FOPDT model.

For an FOPDT fit from a step test, you typically estimate.

1) Process gain Kp = (ΔPV)/(ΔCO) using steady-state changes.

2) Dead time θp as the apparent delay between the CO step and the initial PV response.

3) Time constant τp as the additional time required (after dead time) for the PV to reach about 63% of its total change.

If you have sufficient data, a regression fit to the full time series is usually more accurate than reading a few points by hand, but the same parameters Kp, θp, and τp are still the goal.

3. Choosing the IMC tuning parameter λ (τc).

IMC tuning uses a closed-loop time constant τc (often written as λ) that controls the aggressiveness of the controller.

Smaller τc produces faster tracking and disturbance rejection but increases sensitivity to model mismatch and unmodeled dynamics.

Larger τc produces a slower but more robust loop with smoother manipulated variable movement.

3.1 Practical rules to choose τc.

For many process loops with meaningful dead time, τc is commonly chosen on the order of the dead time to balance speed and robustness.

Some practitioners also choose τc as a multiple of dead time when robustness is prioritized over speed, especially when process parameters drift with production rate or season.

The following table shows commonly used heuristic choices expressed as max functions and multiples, which can be used as starting points before validating in closed-loop tests.

Intent. Starting choice for τc (λ). What to expect. When to avoid.
Fast response with good robustness. τc ≈ θ. Often a good default when the model includes the main delay and lags. Very noisy measurements, strong nonlinearities, or frequent saturation.
More robust response. τc ≈ 3·θ. Smoother response and more tolerance to drift, at the cost of slower recovery. Loops that must reject disturbances quickly to protect equipment or quality.
Heuristic “max” rule example. τc = max(a·τp, b·θp) with a and b selected by plant preference. Forces τc to not be unrealistically small relative to the dominant lag or delay. If τp or θp identification is poor or inconsistent.
Note : If the loop saturates frequently, the effective closed-loop behavior is dominated by constraints, so the best improvement often comes from constraint handling, anti-windup, and operating point changes rather than more aggressive λ.

4. IMC PID tuning correlations for FOPDT models.

4.1 Define the PID algorithm form you are tuning.

Before applying any PID tuning equation, confirm whether your controller uses an ideal (parallel, non-interacting) form or a series (interacting) form, and confirm units for Ti and Td.

Many modern DCS implementations support a non-interacting (parallel) form with a derivative filter and setpoint weighting, and many also allow derivative-on-measurement to avoid derivative kick.

4.2 IMC-PID correlation commonly used for FOPDT.

For an FOPDT model Gp(s) = Kp · e−θp s / (τp s + 1), one IMC-based PID correlation uses τc as the only aggressiveness parameter and computes Kc, Ti, and Td as follows.

Given: Process gain Kp Process time constant τp Process dead time θp Chosen closed-loop time constant τc (λ) IMC-PID settings: Kc = (1 / Kp) * (τp + 0.5*θp) / (τc + 0.5*θp) Ti = τp + 0.5*θp Td = (τp*θp) / (2*τp + θp)

This form is often used as a direct “plug-in” correlation for PID settings once the FOPDT parameters are available.

4.3 IMC-PI (lambda) variant when derivative is not desired.

Many flow and pressure loops work well with PI only, and some IMC-based procedures explicitly recommend PI when derivative adds noise sensitivity without meaningful benefit.

Given: Process gain Kp Process time constant τp Process dead time θp Chosen closed-loop time constant τc (λ) IMC-PI settings: Kc = τp / (Kp * (τc + θp)) Ti = τp Td = 0
Note : If measurement noise is significant, derivative action can amplify noise, so PI is often preferred unless the process shows clear second-order behavior that benefits from derivative damping.

5. IMC-based tuning for SOPDT models using SIMC-style rules.

5.1 Why SOPDT can produce better PID settings than forcing FOPDT.

When the process has two dominant lags, fitting only an FOPDT model can push the delay term or time constant to “absorb” missing dynamics, and that can mislead tuning, especially if you plan to use derivative action.

Using an SOPDT model can support a more intentional use of derivative time to counter the second dominant lag.

5.2 SIMC PID rules for the SOPDT form.

For the SOPDT model Gp(s) = k · e−θ s / ((τ1 s + 1)(τ2 s + 1)), an IMC direct-synthesis approach yields a series-form PID where τc is the tuning parameter and the baseline settings are.

Given: Process gain k Dominant time constant τ1 Second time constant τ2 Effective dead time θ Chosen closed-loop time constant τc (λ) Series-form SIMC settings: Kc = (1 / k) * (τ1 / (τc + θ)) Ti = min(τ1, 4*(τc + θ)) Td = τ2

A frequently used default choice is τc = θ, which yields a compact “memorize-able” form.

If τc = θ: Kc = 0.5 * (1 / k) * (τ1 / θ) Ti = min(τ1, 8*θ) Td = τ2

These SOPDT-oriented rules also imply a practical guideline for when derivative action is most beneficial, because Td is set to the second lag τ2, so derivative is primarily recommended when τ2 is meaningful compared with θ.

5.3 Integrating processes and near-integrating behavior.

For an integrating plus dead time model Gp(s) = k0 · e−θ s / s, the same IMC direct-synthesis framework yields PI-style settings where the integral time is intentionally linked to the chosen τc and θ to avoid slow oscillations.

Given: Integrating gain k0 Effective dead time θ Chosen closed-loop time constant τc (λ) IMC-style integrating settings: Kc = 1 / (k0 * (τc + θ)) Ti = 4*(τc + θ) Td = 0

If you use τc = θ as a starting point, these reduce to Kc = 0.5 / (k0·θ) and Ti = 8·θ.

Note : Level loops that look integrating can change behavior when valves hit stiction, when outflow changes with head, or when measurement filtering is heavy, so validate the model at the operating range that matters.

6. Implementation details that determine whether the tuning works in practice.

6.1 Controller direction, scaling, and sign checks.

IMC equations assume a consistent sign convention for process gain.

If increasing controller output increases the process variable, the process gain is positive and the controller must be configured for the correct action so the feedback is negative.

If increasing controller output decreases the process variable, the process gain is negative and controller action must be reversed accordingly.

6.2 Derivative filtering and derivative kick prevention.

In real systems, derivative is usually implemented with a first-order filter to limit high-frequency noise amplification.

Derivative kick is commonly reduced by applying derivative to the measurement only, not to the setpoint change.

6.3 Anti-windup is not optional when saturation occurs.

If the final element saturates or constraints are active, integral windup can dominate loop behavior and make any IMC tuning look unstable or sluggish.

Use an anti-windup method supported by your controller, such as back-calculation or conditional integration, and verify that the integral term stops accumulating error when the actuator cannot respond.

6.4 Sampling time and filtering must be consistent with τc.

If the loop sample time is too slow compared with the chosen τc, the discrete-time implementation can add effective dead time and destabilize the loop.

As a practical matter, the loop scan and measurement update should be fast enough to represent the process dynamics implied by τc and θ without excessive quantization or delay.

7. Closed-loop validation and systematic fine-tuning.

7.1 A minimal closed-loop test plan.

After entering the IMC PID settings, validate with.

1) A small setpoint step to confirm stable tracking with acceptable overshoot.

2) A load disturbance test if feasible, such as a small upset introduced from an upstream flow or by temporarily changing a known disturbance source.

3) A check for actuator saturation and cycling, especially near constraints.

7.2 Interpreting common symptoms.

Observed behavior. What it usually indicates. Common IMC-style adjustment.
Response is stable but too slow. Closed-loop target τc is too large for the required performance, or Kc is too small. Decrease τc (λ) stepwise, or increase Kc cautiously while monitoring oscillation and saturation.
Sustained oscillations or poor damping. Tuning is too aggressive for the true process delay or unmodeled dynamics, or integral action is too strong under constraints. Increase τc (λ), confirm θ and τ estimates, and verify anti-windup and filtering.
Noise-driven output chatter. Excessive proportional gain, derivative gain, or insufficient measurement filtering. Reduce Kc, reduce or remove derivative, increase derivative filter strength, and review sensor noise sources.
Large overshoot after setpoint changes. Setpoint weighting, integral action, or aggressiveness is mismatched to the target response. Increase τc (λ) or adjust setpoint weighting if available, and verify Ti is implemented in correct units.

7.3 How each PID term affects the loop.

When fine-tuning after IMC initialization, it helps to understand the directional effects of each parameter in standard PID implementations.

Parameter change. Typical effect on speed. Typical effect on stability margin. Typical effect on noise sensitivity.
Increase Kc. Faster. Less robust if increased too far. More sensitive.
Decrease Ti. Faster disturbance removal, stronger integral action. Can reduce robustness and increase oscillation risk. Can increase low-frequency cycling if noise or stiction exists.
Increase Td. Can improve damping for second-order behavior. Can improve or worsen robustness depending on model accuracy and filtering. Often increases sensitivity unless filtered well.
Note : If the model is correct and the loop is not limited by saturation, changing λ (τc) is the most consistent way to move along the speed-versus-robustness trade-off while preserving the IMC structure.

8. A practical end-to-end IMC PID tuning workflow you can standardize.

The following checklist summarizes a repeatable closed-loop PID tuning procedure based on IMC correlations and transfer function identification.

Step. Action. Deliverable. Pass criteria.
1. Plan a safe excitation test at the target operating point. Test plan with step size, duration, and constraints. No violations of safety or quality boundaries.
2. Run a step test and log PV, CO, and key disturbances. Clean time series data. Clear response with adequate signal-to-noise ratio.
3. Fit an FOPDT or SOPDT model (prefer SOPDT if two lags matter). Model parameters (gain, lags, dead time). Model matches step response shape and timing acceptably.
4. Select λ (τc) based on required speed and robustness preference. Chosen τc value. τc is consistent with dead time and implementation limits.
5. Compute IMC PID settings and confirm PID form and units. Kc, Ti, Td and filter choices. Correct sign, correct units, correct algorithm form.
6. Commission with anti-windup and derivative-on-measurement if used. Configured controller. No immediate oscillation or actuator abuse.
7. Validate with setpoint and disturbance tests, then adjust λ if needed. Final λ and PID settings with documentation. Meets performance targets with acceptable robustness and smoothness.

FAQ

Should I use FOPDT or SOPDT for IMC PID tuning.

Use FOPDT when one dominant lag and the dead time explain the response shape well, and the loop does not benefit materially from derivative action.

Use SOPDT when two lags are clearly visible or when a second time constant affects damping, because SOPDT-based rules can use derivative time intentionally rather than relying on an “effective” first-order fit.

What is the main difference between IMC and lambda tuning in practice.

In practical PID tuning, both methods use a desired closed-loop time constant λ (τc) as the main knob, but IMC frameworks typically incorporate dead time explicitly and can produce systematic PID or PI settings derived from the process model form.

When is derivative action most helpful for process control loops.

Derivative action is most helpful when the process has meaningful second-order dynamics where additional damping improves stability and reduces overshoot, and when measurement noise is low enough that a filtered derivative does not create output chatter.

Why does my loop still oscillate even with an IMC-based tuning.

Common causes include an incorrect dead time estimate, unmodeled dynamics such as valve stiction or measurement filtering, actuator saturation without proper anti-windup, or a discrete sampling and communication delay that increases effective dead time beyond what the model captured.

How do I speed up the loop without making it unstable.

The most consistent IMC-style approach is to reduce λ (τc) stepwise and retest, because λ directly sets the intended closed-loop speed in the tuning correlations.

If your implementation is PI-only, increasing Kc and decreasing Ti will generally speed up response, but these changes should be made cautiously while monitoring oscillation, saturation, and output variation.

:
