Reactor Conversion Sensitivity Analysis for Feed Temperature, Pressure, and Composition Optimization
The purpose of this article is to provide a rigorous, practical workflow to quantify how reactor conversion changes with feed conditions so that engineers can prioritize controllable levers, reduce variability, and improve process optimization decisions.
1. What “conversion sensitivity” means in process engineering.
Conversion sensitivity quantifies how strongly the outlet conversion responds to small changes in feed conditions such as feed temperature, feed concentration, feed flow rate, pressure, and inert dilution ratio.
Let conversion be defined for reactant A as X = (FA0 − FA)/FA0 for steady state operation.
A local sensitivity is commonly written as a partial derivative such as ∂X/∂T0, ∂X/∂CA0, or ∂X/∂P0 evaluated at a specified base-case feed condition.
Because feed variables have different units and scales, a dimensionless sensitivity is often more interpretable for ranking and control planning.
A widely used dimensionless metric is an elasticity, defined as Eu = (u/X)·(∂X/∂u), where u is a feed variable such as T0 or CA0.
An elasticity near zero indicates weak influence around the base point, while a large magnitude indicates a strong lever for conversion optimization or a strong source of variability.
2. Model foundation needed for defensible sensitivity results.
Sensitivity analysis is only as reliable as the reactor model used to compute conversion.
A minimum viable model includes a material balance, a kinetic rate expression, and any energy balance needed to capture temperature effects on reaction rate and equilibrium.
2.1. Typical steady-state reactor models used for conversion sensitivity.
For a plug flow reactor with axial coordinate V, a common form is dFA/dV = νA·r(C,T,P), where νA is the stoichiometric coefficient for A and r is the volumetric rate.
For an isothermal CSTR, the steady-state material balance can be written as FA0 − FA + νA·r(C,T,P)·V = 0.
If temperature varies, an energy balance is required, and conversion sensitivity with respect to feed temperature or cooling conditions becomes a coupled problem.
Note : If conversion depends on temperature through Arrhenius kinetics and also depends on temperature through equilibrium limitations, a model that omits equilibrium or heat effects can produce sensitivities with the wrong sign and magnitude.
2.2. A concrete kinetics example that exposes the main sensitivity pathways.
For many catalytic or homogeneous reactions, a baseline kinetic form is r = k(T)·f(C,P), where k(T) follows an Arrhenius law k(T) = k0·exp(−Ea/(R·T)).
In this structure, feed temperature affects conversion through k(T) and through any temperature dependence of density, heat capacity, and equilibrium constants that change the attainable conversion.
Feed composition affects conversion through f(C,P) and through mixture properties that shift partial pressures and residence time.
3. A practical workflow that engineers can apply immediately.
A defensible workflow separates local sensitivity for quick ranking from global sensitivity for uncertainty and nonlinearity.
The sequence below is widely used in reactor troubleshooting and process optimization studies.
3.1. Step 1. Define the base case and the conversion target consistently.
Define a single base-case feed vector u0 that includes T0, P0, total feed flow, component flow rates, and any inert or recycle ratio.
Define conversion consistently for the limiting reactant and confirm the definition remains valid when the feed changes, especially when the limiting reactant can switch under composition perturbations.
3.2. Step 2. Choose the sensitivity outputs that match the decision being made.
If the goal is throughput optimization, sensitivities with respect to total feed rate and residence time are central.
If the goal is robustness, elasticities with respect to uncertain feed composition or feed temperature fluctuations are central.
If the goal is control design, sensitivities with respect to manipulated variables such as preheater outlet temperature, dilution, and pressure setpoint are central.
3.3. Step 3. Compute local sensitivities using stable finite differences.
Finite differences provide a simple and transparent estimate of ∂X/∂u around the base case.
A central difference typically reduces truncation error compared to a forward difference when the model is smooth around the base point.
A central difference approximation is ∂X/∂u ≈ (X(u0+Δu) − X(u0−Δu))/(2·Δu).
| Feed variable u | Common physical meaning | Practical perturbation rule for Δu | Reason for the rule |
|---|---|---|---|
| T0 | Preheat or upstream heat integration. | Use ΔT of 1 K to 5 K when the model includes energy balance and constraints. | Small enough to remain local, large enough to overcome numerical noise. |
| P0 | Compressor discharge or backpressure control. | Use ΔP of 0.5% to 2% of the base pressure for gas-phase systems. | Pressure effects can be nonlinear through partial pressures and density. |
| CA0 or yA0 | Feed quality and blending. | Use Δy of 0.1% to 1% absolute while preserving sum of mole fractions. | Composition changes must maintain physical feasibility and normalization. |
| Ftot,0 | Throughput and residence time. | Use ΔF of 0.5% to 2% of base flow with consistent residence time definitions. | Throughput changes can shift both kinetics and heat transfer regimes. |
| Inert fraction | Dilution and temperature moderation. | Use Δyinert of 0.5% to 2% absolute with renormalization. | Dilution changes partial pressures and heat capacity simultaneously. |
Note : When constraints exist such as maximum temperature, pressure drop limits, or maximum coolant duty, a finite-difference perturbation must enforce the same constraint logic in both perturbed simulations, otherwise the computed sensitivity mixes physics with constraint switching artifacts.
3.4. Step 4. Convert raw derivatives into decision-ready elasticities.
Compute elasticities Eu = (u/X)·(∂X/∂u) for ranking feed levers across different units.
If X is close to zero, replace elasticities with scaled absolute sensitivities such as (∂X/∂u)·uref where uref is a chosen reference scale.
4. Differential sensitivity equations for higher accuracy and speed.
When the reactor model is expressed as differential equations, sensitivities can be computed by augmenting the system with additional sensitivity states.
This approach is often more accurate than finite differences and can be more efficient when many sensitivities are needed at the same base case.
4.1. General formulation for steady-state plug flow models.
Let the reactor state vector be y(V) and let the model be dy/dV = f(y, p, V), where p is a parameter or feed condition being analyzed.
Define the sensitivity vector S(V) = ∂y/∂p.
The sensitivity equations are dS/dV = (∂f/∂y)·S + ∂f/∂p.
The required Jacobians can be computed analytically for simple kinetics or numerically using consistent internal differentiation rules.
4.2. How feed temperature enters when the reactor is non-isothermal.
In a non-isothermal model, temperature is part of the state vector, and feed temperature affects the initial condition and can affect boundary conditions for heat transfer.
If the model uses an energy balance like dT/dV = g(y,T,heat transfer), then S includes ∂T/∂T0 as a sensitivity state in addition to concentration sensitivities.
Coupling between concentration and temperature sensitivities can produce strong positive feedback for exothermic reactions with insufficient heat removal.
Note : Exothermic reactors can exhibit multiple steady states in certain operating windows, and local sensitivities computed on one branch do not represent behavior after a branch jump, so sensitivity results must be interpreted together with the steady-state map.
4.3. Outlet conversion sensitivity extraction.
If conversion is computed from outlet flows, then ∂X/∂p can be obtained from outlet sensitivities of FA and FA0 using consistent differentiation of X = (FA0 − FA)/FA0.
If FA0 is itself the perturbed variable, the derivative must include the dependence of both numerator and denominator on p.
5. Adjoint sensitivity for many feed variables and few outputs.
When the number of feed variables is large and the number of outputs is small, adjoint sensitivity methods can be computationally advantageous.
The adjoint approach computes the gradient of an output such as outlet conversion with respect to many inputs using one backward integration per output rather than one forward sensitivity integration per input.
In process optimization workflows, this supports fast computation of gradients needed by constrained optimizers and real-time optimization schemes.
5.1. When the adjoint method is most beneficial.
The adjoint method is most beneficial when conversion is the primary objective and the feed vector includes many degrees of freedom such as detailed composition, multiple inlet temperatures, and multiple pressure boundary conditions.
The method is also beneficial when global optimization loops require repeated gradients at many base points.
6. Interpreting sensitivities with chemical engineering insight.
Sensitivity signs and magnitudes should be interpreted using kinetics, thermodynamics, and transport constraints rather than treated as purely mathematical outputs.
6.1. Temperature sensitivity patterns that commonly appear.
For kinetically limited reactions without strong equilibrium limitation, increasing feed temperature typically increases rate constants and can increase conversion at fixed residence time.
For equilibrium-limited exothermic reactions, increasing temperature can reduce equilibrium conversion even if kinetics accelerate, so the net sign of ∂X/∂T0 depends on which effect dominates at the operating point.
For endothermic equilibrium-limited reactions, increasing temperature can increase equilibrium conversion and often increases conversion if heat supply is adequate.
6.2. Pressure and dilution sensitivity patterns for gas-phase reactions.
For reactions that reduce total moles in the gas phase, increasing pressure can increase reactant partial pressures and shift equilibrium toward products, which can increase conversion.
For reactions that increase total moles, increasing pressure can reduce equilibrium conversion even if rates increase with partial pressure, so pressure sensitivity can be mixed.
Inert dilution can reduce reactant partial pressures and reduce rates, while also moderating temperature rise and improving selectivity in some systems, so conversion sensitivity to dilution should be evaluated with the full model constraints.
6.3. Throughput sensitivity and the residence time mechanism.
If reactor volume is fixed, increasing total feed flow decreases residence time and commonly decreases conversion for kinetically limited systems.
If the reactor operates under a fixed pressure drop limit or fixed heat removal capacity, throughput changes can shift operating regimes, and sensitivity can change sharply near constraints.
| Observed sensitivity outcome | Likely dominant mechanism | Diagnostic check | Typical optimization response |
|---|---|---|---|
| Large positive ∂X/∂T0. | Kinetic limitation dominates. | Confirm Arrhenius dependence and ensure equilibrium is not limiting. | Increase preheat within safety and materials limits. |
| Negative ∂X/∂T0 at high conversion. | Equilibrium limitation for exothermic system dominates. | Compute equilibrium conversion at outlet temperature and compare to model conversion. | Lower feed temperature or enhance heat removal to reduce outlet temperature. |
| Large negative ∂X/∂Ftot,0. | Residence time limitation dominates. | Evaluate Damköhler number trend with flow and validate mixing assumptions. | Reduce throughput or increase active volume or catalyst activity. |
| Strong sensitivity to inert fraction. | Partial pressure and heat capacity effects dominate. | Track partial pressures, adiabatic temperature rise, and reaction order. | Optimize dilution to balance rate and thermal constraints. |
7. Presenting results for stakeholders and for control tuning.
To make sensitivity analysis actionable, convert computed sensitivities into ranked levers and communicate the operating window where the ranking is stable.
A common approach is to compute elasticities at multiple base points across a feasible feed envelope and summarize rankings using a table or a tornado-style ranking list.
For control applications, sensitivities should be paired with expected feed disturbance magnitudes to estimate expected conversion variance.
7.1. Minimal reporting package that supports process decisions.
A minimal reporting package includes the base-case feed conditions, the computed conversion, local sensitivities, elasticities, and the perturbation sizes or sensitivity formulation used.
The report also includes constraint status at the base case and at perturbed cases to confirm the sensitivities reflect physics rather than constraint switching.
8. Implementation template that can be translated into any simulator or code base.
The following algorithm outlines a robust finite-difference implementation for conversion sensitivity with respect to feed conditions.
1) Define base-case feed vector u0 = [T0, P0, Ftot0, y0, ...]. 2) Run the reactor model at u0 and compute base conversion X0. 3) For each feed variable ui in u0: 3.1) Choose perturbation Δui using an engineering rule and numerical noise tests. 3.2) Create u_plus by adding Δui while enforcing feasibility constraints and normalization rules. 3.3) Create u_minus by subtracting Δui while enforcing feasibility constraints and normalization rules. 3.4) Run the reactor model at u_plus and compute X_plus. 3.5) Run the reactor model at u_minus and compute X_minus. 3.6) Compute derivative dX_dui = (X_plus - X_minus) / (2 * Δui). 3.7) Compute elasticity Ei = (ui / X0) * dX_dui when X0 is sufficiently away from zero. 4) Rank variables by |Ei| for dimensionless ranking and by |dX_dui| for absolute impact ranking. 5) Repeat at multiple base points across the expected feed envelope to assess ranking stability.Note : If the reactor model uses iterative solvers for recycle, heat integration, or equation-of-state flashes, numerical tolerances must be tighter than the perturbation effect you want to measure, otherwise solver noise can dominate the sensitivity.
FAQ
How do I choose perturbation sizes for feed sensitivity without getting numerical noise.
Use perturbations that are small enough to remain in the local linear region but large enough to exceed solver tolerances and convergence noise.
Start with relative changes of 0.5% to 2% for flows and pressures, and 1 K to 5 K for temperatures, then reduce the step and confirm the derivative stabilizes.
If the derivative changes significantly when the step is halved, the model is either strongly nonlinear at the base point or the solver noise is comparable to the perturbation signal.
What does it mean if the sensitivity sign changes when I change the base feed condition.
A sign change indicates that different mechanisms dominate in different regions of the operating space.
Common causes include a shift from kinetic limitation to equilibrium limitation, activation of thermal constraints, or changes in limiting reactant due to composition shifts.
In this case, compute sensitivities across a grid of feasible feed conditions and map where each mechanism dominates.
How should I treat feed composition sensitivities when mole fractions must sum to one.
Use a constrained perturbation that increases one component while decreasing one or more others so that the sum of mole fractions remains one.
A common approach is to perturb one key component and renormalize the remaining components proportionally, while documenting the renormalization rule in the sensitivity report.
This ensures the perturbed cases remain physically feasible and avoids sensitivities that depend on an impossible feed specification.
When should I use differential sensitivity equations or adjoint sensitivity instead of finite differences.
Use differential sensitivity equations when your reactor model is expressed as differential equations and you need higher accuracy or many sensitivities at a single base point.
Use adjoint sensitivity when you have many feed variables but only a few outputs such as a single outlet conversion, because it can compute gradients more efficiently for optimization.
Finite differences remain useful for quick screening, validation of derivative sign, and cross-checking more advanced methods.
